Autometer Oil Pressure Gauge Question

[ThePope]

I am interested in install a oil pressure gauge in my 98 GT. I wanna go electric. I wanted to know if there are any write ups on how it install it or has anyone done it?



[Jrgunn5150]

I have one, I just used a T-fitting on the stock sender.



[ThePope]

I have one, I just used a T-fitting on the stock sender.

Where would the stock sender be located? Do you remember which t-fitting you used?



[Jrgunn5150]

It's just above the oil filter, easier to see with the filter off. The T I used was a standard NPT hardware store item, sorry not sure on the size. i want to say either 1/8 or 1/4 NPT though.



[ThePope]

It's just above the oil filter, easier to see with the filter off. The T I used was a standard NPT hardware store item, sorry not sure on the size. i want to say either 1/8 or 1/4 NPT though.

Ok cool. Now one more question. I wanna use a autometer pro comp ultra light series gauge. Should I get the full sweep or short sweep?



[Jrgunn5150]

I would get the full sweep since mod motor's run alot of pressure, not like an old 351m with like 12 psi, lol.



[MustangMatt96GT]

Well i have a short sweep. I just installed it the other day! Actually you dont need a T. In the pictures below, u can see a plug that has an allen head on it. U just take that off and the put in the 1/4 inch fitting that reduces to 1/8 inch. Then you just run your wire up to your gauge pod. Its really easy. Ill include the link that i used to tap my wires for power and evertying a video and those pics!
http://www.miracerros.com/mustang/gauge.html



[Jrgunn5150]

Nice pics!



[ThePope]

Thanks MustangMatt96GT!! You made me life 100% easier. Looks great too.



[97gtconv.]

nice, good thread. I'm buying a gauge tonight



[scarface]

wow nice thread guys...this will help a ton of people.
